Function Code Table
MD380 User Manual
- 92 -
Function
Code
Parameter Name
Setting Range
Default Property
F4-38 DI valid mode selection 1
Thousand's digit (DI4 valid mode)
00000 ★
0, 1 (same as DI1)
Ten thousand's digit (DI5 valid
mode)
0, 1 (same as DI1)
F4-39 DI valid mode selection 2
Unit's digit (DI6 valid mode)
00000 ★
0, 1 (same as DI1)
Ten's digit (DI7 valid mode)
0, 1 (same as DI1)
Hundred's digit (DI8 state)
0, 1 (same as DI1)
Thousand's digit (DI9 valid mode)
0, 1 (same as DI1)
Ten thousand's digit (DI10 valid
mode)
0, 1 (same as DI1)
F4-40 AI2 input signal selection
0: Voltage signal
1: Current signal
0 ★
Group F5: Output Terminals
F5-00 FM terminal output mode
0: Pulse output (FMP)
1: Switch signal output (FMR)
0 ☆
F5-01
FMR function (open-
collector output terminal)
0: No output
1: AC drive running
2: Fault output (stop)
3: Frequency-level detection
FDT1 output
4: Frequency reached
5: Zero-speed running (no output
at stop)
6: Motor overload pre-warning
7: AC drive overload pre-warning
8: Set count value reached
9: Designated count value
reached
10: Length reached
11: PLC cycle complete
12: Accumulative running time
reached
13: Frequency limited
2 ☆
F5-02 Relay function (T/A-T/B-T/C) 2 ☆
