MD380 User Manual Function Code Table
- 95 -
Function
Code
Parameter Name
Setting Range
Default Property
F5-22 DO valid mode selection
Unit's digit (FMR valid mode)
00000 ☆
0: Positive logic
1: Negative logic
Ten's digit (Relay 1 valid mode)
0, 1 (same as FMR)
Hundred's digit (Relay 2 valid
mode)
0, 1 (same as FMR)
Thousand's digit (DO1 valid
mode)
0, 1 (same as FMR)
Ten thousand's digit (DO2 valid
mode)
0, 1 (same as FMR)
F5-23 AO1 output signal selection
0: Voltage signal
1: Current signal
0 ★
Group F6: Start/Stop Control
F6-00 Start mode
0: Direct start
1: Rotational speed tracking
restart
2: Pre-excited start (asynchronous
motor)
0 ☆
F6-01
Rotational speed tracking
mode
0: From frequency at stop
1: From zero speed
2: From maximum frequency
0 ★
F6-02
Rotational speed tracking
speed
1–100
20 ☆
F6-03 Startup frequency
0.00–10.00 Hz
0.00 Hz ☆
F6-04
Startup frequency holding
time
0.0–100.0s
0.0s ★
F6-05
Startup DC braking current/
Pre-excited current
0%–100%
0% ★
F6-06
Startup DC braking time/
Pre-excited time
0.0–100.0s
0.0s ★
F6-07
Acceleration/Deceleration
mode
0: Linear acceleration/
deceleration
1: S-curve acceleration/
deceleration A
2: S-curve acceleration/
deceleration B
0 ★
