Function Code Table
MD380 User Manual
- 96 -
Function
Code
Parameter Name
Setting Range
Default Property
F6-08
Time proportion of S-curve
start segment
0.0% to (100.0% – F6-09)
30.0% ★
F6-09
Time proportion of S-curve
end segment
0.0% to (100.0% – F6-08)
30.0% ★
F6-10 Stop mode
0: Decelerate to stop
1: Coast to stop
0 ☆
F6-11
Initial frequency of stop DC
braking
0.00 Hz to maximum frequency
0.00 Hz ☆
F6-12
Waiting time of stop DC
braking
0.0–36.0s
0.0s ☆
F6-13 Stop DC braking current
0%–100%
0% ☆
F6-14 Stop DC braking time
0.0–36.0s
0.0s ☆
F6-15 Brake use ratio
0%–100%
100% ☆
Group F7: Operation Panel and Display
F7-01 MF.K Key function selection
0: MF.K key disabled
1: Switchover between operation
panel control and remote
command control (terminal or
communication)
2: Switchover between forward
rotation and reverse rotation
3: Forward JOG
4: Reverse JOG
0 ★
F7-02 STOP/RESET key function
0: STOP/RESET key enabled
only in operation panel control
1: STOP/RESET key enabled in
any operation mode
1 ☆
F7-03
LED display running
parameters 1
0000–FFFF
Bit00: Running frequency 1 (Hz)
Bit01: Set frequency (Hz)
Bit02: Bus voltage (V)
Bit03: Output voltage (V)
Bit04: Output current (A)
Bit05: Output power (kW)
Bit06: Output torque (%)
Bit07: DI input status
1F ☆
