MD380 User Manual Function Code Table
- 97 -
Function
Code
Parameter Name
Setting Range
Default Property
F7-03
LED display running
parameters 1
Bit08: DO output status
Bit09: AI1 voltage (V)
Bit10: AI2 voltage (V)
Bit11: AI3 voltage (V)
Bit12: Count value
Bit13: Length value
Bit14: Load speed display
Bit15: PID setting
1F ☆
F7-04
LED display running
parameters 2
0000–FFFF
Bit00: PID feedback
Bit01: PLC stage
Bit02: Pulse setting frequency
(kHz)
Bit03: Running frequency 2 (Hz)
Bit04: Remaining running time
Bit05: AI1 voltage before
correction (V)
Bit06: AI2 voltage before
correction (V)
Bit07: AI
3 voltage
before correction (V)
Bit08: Linear speed
Bit09: Current power-on time
(Hour)
Bit10: Current running time (Min)
Bit11: Pulse setting frequency
(Hz)
Bit12: Communication setting
value
Bit13: Encoder feedback speed
(Hz)
Bit14: Main frequency X display
(Hz)
Bit15: Auxiliary frequenc
y Y
display (Hz)
0 ☆
