Function Code Table
MD380 User Manual
- 92 -
Function
Code
Parameter Name
Setting Range
Default Property
Group F3: V/F Control Parameters
F3-00 V/F curve setting
0: Linear V/F
1: Multi-point V/F
2: Square V/F
3: 1.2-power V/F
4: 1.4-power V/F
6: 1.6-power V/F
8: 1.8-power V/F
9: Reserved
10: V/F complete separation
11: V/F half separation
0 ƾ
F3-01 Torque boost
¿[HGWRUTXHERRVW
0.1%–30.0%
Model
dependent
ƿ
F3-02
Cut-off frequency of torque
boost
0.00 Hz to maximum frequency
50.00 Hz ƾ
F3-03
Multi-point V/F frequency 1
(F1)
0.00 Hz to F3-05
0.00 Hz ƾ
F3-04
Multi-point V/F voltage 1
(V1)
0.0%–100.0%
0.0% ƾ
F3-05
Multi-point V/F frequency 2
(F2)
F3-03 to F3-07
0.00 Hz ƾ
F3-06
Multi-point V/F voltage 2
(V2)
0.0%–100.0%
0.0% ƾ
F3-07
Multi-point V/F frequency 3
(F3)
F3-05 to rated motor frequency
(F1-04)
0.00 Hz ƾ
F3-08
Multi-point V/F voltage 3
(V3)
0.0%–100.0%
0.0% ƾ
F3-09 V/F slip compensation gain
0.0%–200.0%
0.0% ƿ
F3-10 V/F over-excitation gain
0–200
64 ƿ
F3-11
V/F oscillation suppression
gain
0–100
Model
dependent
ƿ
