8,000 BTU Portable Air Conditioner
www.insigniaproducts.com
Control panel
# Item Description
1 Remote control receiver Receives signals from the remote control. Do not block.
2 LED Display
Temp eratu re /Ti me
display
Shows the temperature and time left on the timer.
3 TIMER button Press to set the air conditioner to turn on or off automatically.
4 MODE button Press to cycle the air conditioner through the available modes. Options include COOL,
FAN, and AUTO.
5
(TEMP/TIMER)
buttons
COOLING mode–press to raise or lower the temperature setting. Press at the same time to
change from Fahrenheit to Celsius.
TIMER mode–press to turn the timer on or off.
6 SPEED button Press to select low or high speed.
7 Power button Press to turn the air conditioner on or off.
