10
NS-BC1ZSS9
www.insigniaproducts.com
2 Remove the upper hinge bolt (1) and lift the door off the cooler.
3 To reverse the cooler’s hinges:
A Remove the three screws (2) securing the upper hinge (3) and the three
plastic caps (4) at the top left side of the cooler. Set the upper hinge aside
and save it in case you need to reverse the door again.
Note: If you reverse the door a second time, the hinge will be on the right side of the
cooler.
