10
NS-CF26PK7/NS-CF26BL7/ NS-CF26BL7-C/NS-CF26BK8
www.insigniaproducts.com
1 The first time you turn the refrigerator on, adjust the thermostat to “7”
and run for at least two hours before putting food in.
2 After it is fully cooled, test it and adjust towards “4” to make it less cool,
to best suit your needs. The “4” setting should be appropriate for
home or office refrigerator use.
Reversing the door position
You will need: A 10 mm socket driver and a Phillips screw driver available.
• Make sure that your refrigerator is unplugged and empty.
• Have someone available to assist you in the process.
• Keep all of the parts you remove to reuse them later.
• Removing the door requires that the refrigerator be tilted backwards. Rest
the refrigerator on something solid, such as a chair, just below the top
panel.
• Do not lay the refrigerator completely flat so that you do not damage the
coolant system.
1 Remove the screw holding the top hinge cover to the top of your
refrigerator, then remove the top hinge cover.
2 Remove the screws holding the top hinge to your refrigerator, then
remove the hinge.
3 Remove the screw hole covers from the top left side of your
refrigerator.
Notes
• Turning the thermostat “OFF” stops the cooling cycle but
does not shut off the power to the refrigerator.
• If the refrigerator. is unplugged or loses power, you must
wait three to five minutes before restarting it. If you
attempt to restart before this time delay, the refrigerator
will not start.
• Large amounts of food will lower the cooling efficiency of
the refrigerator.
• If you choose to change the thermostat setting, adjust it
one increment at a time. Allow several hours for
temperature to stabilize between adjustments.
NS-CF26PK7_NS-CF26BL7_NS-CF26BL7-C_NS-CF26BK8_17-0448_MAN_V5_ENG.fm Page 10 Wednesday, June 14, 2017 11:48 AM
