10
www.insigniaproducts.com
Reversing the door
You need the following tools to reverse the door:
1 Remove the hinge cover and the three screws that secure the hinge to the top
right of the refrigerator compartment. Remove the screw hole covers on the
top left side.
2 Lift the refrigerator door up and remove it.
3 Move the door bushing from the right side of the door to the left, then move
the plastic hole cover from the left side of the door to the right.
4 Remove the screw that secures the door stop to the bottom right side of the
refrigerator door. Use the screw to secure the door stop to the bottom left side
of the door.
CAUTION: If you lay your refrigerator on its back or side for any length of time,
wait for six hours after you stand it up again before you plug it in. Otherwise,
you may damage internal components.
8mm nut driver
Phillips screwdriver
5mm nut driver
Hinge cover and screws
Screw covers
Plastic hole cover
Door bushing
