11
4.1 Cu. Ft. Bottom Mount Compact Refrigerator
www.insigniaproducts.com
5 Remove the center hinge from the right side of the refrigerator. Remove the
screw hole covers from the left side of the refrigerator.
6 Lift the freezer door up and remove it.
7 Move the door bushing from the right side of the door to the left and the
plastic hole cover from the left side of the door to the right.
8 Remove the screw that secures the door stop to the bottom right side of the
freezer door. Use the screw to secure the door stop to the bottom left side of
the door.
9 Unscrew and remove the lower hinge and leveling feet from the bottom front
of the cabinet.
Plastic hole cover
Door bushing
To Next Page
