10 Use a nut driver to remove the lower hinge pin from the hinge, then flip the
hinge over and install the hinge pin in the opposite side.
11 Use the two screws you removed earlier to secure the lower hinge to the
bottom left side of the freezer compartment. Install both adjustable feet.
12 Install the freezer door. Install the center hinge on the left side of the
refrigerator. Install the screw hole covers on the right side.
13 Install the refrigerator door. Install the upper hinge and the hinge cover on the
top left side of the refrigerator compartment. Install the screw hole cover on
the top right side of the compartment.
Note: Make sure that the rubber gaskets make a good seal with the cabinet all
the way around the doors before tightening the hinge screws.
