www.insigniaproducts.com
11
NS-RBM11SS2/NS-RBM11SS2-C/NS-RBM11WH2/NS-RBM11WH2-C
5 Remove the freezer door.
6 Remove the screws holding the right-side lower hinge, then remove the hinge and the pivot shaft from it.
7 Install the pivot shaft on the other side of the lower hinge, then install the hinge on the left side of the refrigerator,
using the screws you just removed.
8 Remove the hole cover from the top-left side of the refrigeration door, remove the shaft sleeve from the top-right side
of the refrigerator door, then remove the stopper from the bottom-right side of the refrigerator door.
9 Install the hole cover in the top-right side of the refrigerator door, install the shaft sleeve in the top-left side of the door,
then install the stopper into the bottom-left side of the refrigerator door.
CAUTION: Be careful not to lose any of the small parts, such as the shaft sleeve and door stop.
Right-side
lower hinge
Pivot shaft
Shaft sleeve
Stopper
Hole cover
Stopper
Hole cover
Shaft sleeve
To Next Page
