www.insigniaproducts.com
12
10 Remove the shaft sleeve from the top-right side of the freezer door, remove the hole cover from the top-left side of the
freezer door, then remove the stopper from the bottom-right side of the freezer door.
11 Install the hole cover in the top-right side of the freezer door, install the shaft sleeve in the top-left side of the door, then
install the stopper into the bottom-left side of the freezer door.
12 Install the freezer door on the lower hinge, then install the middle hinge on the middle-left side of the refrigerator and
the hole cover on the middle-right side of the refrigerator.
13 Remove the upper left hinge cover and upper left hinge from the accessory bag.
Hole cover
Shaft sleeve
Stopper
Hole cover
Shaft sleeve
Stopper
