Insignia NS-RBM92BK9 User Manual

www.insigniaproducts.com
11
NS-RBM92BK9/NS-RBM92WH9
4 Remove the refrigerator compartment door from the cabinet.
5 Remove the two screws that secure the center hinge, then remove the center hinge and the center hinge spacer.
6 Remove the freezer compartment door.
7 Move the door bushing from the top right side of the freezer door to the top left side of the door.
Hinge cover
Screws
Upper hinge
Hinge screw hole
cover
Screw
Center hinge spacer
Center hinge
Screws Door bushing
Door bushing

Insignia NS-RBM92BK9 Specifications

General

Brand	Insignia
Model	NS-RBM92BK9
Category	Refrigerator
Language	English
