www.insigniaproducts.com
12
9.2 Cu. Ft. Bottom-Mount Refrigerator
8 Remove the screw that secures the door stops from the bottom of the freezer door, then remove the door stops.
9 Remove the four screws that secure the lower hinge to the right side of the cabinet, then remove the hinge.
10 Install the lower hinge on the left side of the cabinet.
11 Remove the washer and nut that secure the pin shaft to the right hole on the lower hinge, then remove the shaft.
12 Insert the pin shaft into the left hole on the lower hinge, then secure the shaft with the washer and nut.
Door stopDoor stop
Lower hinge
Screws
Pin shaft
Washer
Nut
To Next Page
