www.insigniaproducts.com
13
NS-RFD26SS9/NS-RFD26SS9-C
Removing the refrigerator doors (Optional)
If the opening to the installation area you chose is too narrow for your refrigerator to pass through, remove the doors and
drawers, then move your refrigerator sideways into the area.
You will need the following tools to remove the refrigerator doors:
1 Make sure that your refrigerator is unplugged.
2 With the refrigerator compartment doors shut, remove the three screws that secure the cover on the top of your
refrigerator, then remove the cover with the attached harness assemblies.
3 Use an 8 mm wrench to remove the three hinges screws, use a Phillips screwdriver to remove the ground screw, then
remove the hinges.
Note: Do not remove the doors unless you have to.
Phillips screwdriver
8mm wrench
5 mm Allen wrench
Flat-blade screwdriver
Ground screw
Hinge screws
Hinge
To Next Page
