IF1200A Pilot Operating Handbook 10. Assemble the Aircraft
Repeat the previous steps to assemble the second landing gear.
The next steps involve lifting the aircraft body out of the shipping container with one
hand, and attaching the assembled landing gear to it with the other hand. Place the
assembled landing gears close to the shipping container for easy access.
● The aircraft weighs 7.7 Kg (17 lbs), without batteries.
● In Figure 11 below, the propeller holders hold the propellers stationary on the
arms for transporting or storing the aircraft. Reference is made to these later in
this procedure.
Grasp the handle on the IF1200A body (see below), and gently remove the aircraft
from the shipping container.
Grasp the handle at the center; DO NOT pull or lift the GPS antenna
on either end of the handle, as this could damage the vehicle. Verify
that the handle is locked in place, in the upright position.
Figure 12. Aircraft Handle and Foam Propeller Holders
IFT Doc Num 102094, Rev 1.02 Page 19
