Inspired Flight IF1200A - Install the Flight Batteries

IF1200A Pilot Operating Handbook 11. Install the Flight Batteries
11. Install the Flight Batteries
Step
Action
1
Locate the battery platform on the top of the aircraft (see below). The handle (see
graphic), has three functions:
● Carry/lifting handle for the aircraft
● GPS antenna: a dual GPS system is used, with an antenna on both ends of
the handle.
● Clamp the batteries in place.
2
Place the batteries in the rubber alignment pads on the battery platform. Ensure the
batteries are oriented so that their cables are towards the rear of the aircraft, as
shown above. Ensure the batteries are seated firmly between the side, front, and rear
mounts.
Continued next page
IFT Doc Num 102094, Rev 1.02 Page 23
