IF1200A Pilot Operating Handbook 10. Assemble the Aircraft
Tighten the clamps (see figure below), until snug, then tighten a quarter turn
more.
Extend the remaining arms fully, and lock them into position.
Gently remove the foam propeller holders that secure the propellers to the
arms. Save the propeller holders for future use.
Completely unfold all of the propellers.
Completely unfold all propellers before takeoff to avoid possible
damage to the aircraft.
Figure 15. Landing Gear Clamp
IFT Doc Num 102094, Rev 1.02 Page 22
