IF1200A Pilot Operating Handbook 10. Assemble the Aircraft
Step
Action
9
Extend and lock the two arms that are above the landing gear sockets (see below).
10
Locate the clamps on the landing gear sockets and loosen them (see the Figure on
next page).
11
Insert the landing gear into the two sockets in the bottom of the aircraft (see below).
Ensure the landing gear are fully inserted in the sockets. Place the aircraft on a clean
work surface, on the landing gear, for the remainder of the assembly procedure.
Continued next page
Figure 14. Arms Extended for Installing Landing Gear
IFT Doc Num 102094, Rev 1.02 Page 21
