Instron 2716-010 - Page 22

Chapter: Specifications
22 M10-14052-EN
Table 3. Jaw Face Specifications
Catalog
Number
Specimen
Type
Specimen
Thickness
mm (in) Surface
2703-151 Flat 0 to 6.4
(0 to 0.25)
1.5mm pitch (16 teeth per in.)
2703-152 Flat 6.4 to 12.6
(0.25 to 0.50)
1.5mm pitch (16 teeth per in.)
2703-155 Flat 0 to 6.4
(0 to 0.25)
1mm pitch (25 teeth per in.)
2703-156 Flat 6.4 to 12.6
(0.25 to 0.50)
1mm pitch (25 teeth per in.)
2703-157 Flat 0 to 6.4
(0 to 0.25)
Surfalloy coated (emery grit of 100)
2703-158 Flat 6.4 to 12.6
(0.25 to 0.50)
Surfalloy coated (emery grit of 100)
2703-160 Flat 0 to 6.4
(0 to 0.25)
Rubber coated (emery grit of 100)
2703-153 Round 3.2 to 7.8
(0.12 to 0.31)
Diameter
1mm pitch (25 teeth per in.)
2703-154 Round 7.1 to 12.6
(0.28 to 0.50)
Diameter
1mm pitch (25 teeth per in.)
Table 4. 2716-020 (50 kN) Ranges for Specimen Thickness
Catalog
Number
Specimen
Type Specimen Thickness Surface
With Spacers
mm (in)
Without Spacers
mm (in)
2703-151 Flat 0 to 6.4
(0 to 0.25)
5 to 11.4
(0.20 to 0.45)
1.5mm pitch (16 teeth
per in.)
2703-152 Flat 6.4 to 12.6
(0.25 to 0.50)
11.4 to 17.6
(0.45 to 0.70)
1.5mm pitch (16 teeth
per in.)
2703-155 Flat 0 to 6.4
(0 to 0.25)
5 to 11.4
(0.20 to 0.45)
1mm pitch (25 teeth per
in.)
