Chapter: Illustrated Parts
44 M10-14052-EN
Table 6. 2716-010 (5 kN) Wedge Grip - Parts List
Item Description Part Number Quantity
1Screw M4 x 8 201S87 1
2 Bearing Pad T566-5 1
3 Body T566-4 1
4 Control Nut T566-2 1
5 Spindle T566-1 1
6 Pin, 10 x 35 54-53-1054 1
7Check Nut T2-309 1
8 Handle T566-7 2
9 Bearing Washer T566-3 1
10 Pin, 6 x 14 54-53-1053 1
11 Pin, 1/4 x 1 in. 54-5-11 4
12 Pin, 5/32 x 1 in. 26-6-2 4
13 Spring Extension 66-1-1069 4
14 Side Plate T566-6 2
15 Screw M4 x 8 204F123 4
16 Specimen Centering Device
Including:
2716-011 1
Bracket T566-14 1
Thumbscrew 71-2-55 1
Stop T566-115 1
Screws 201T98 2
17 Faces Refer to
Table 3 on page 22
2 pair
