Chapter: Illustrated Parts
46 M10-14052-EN
Table 8. 2736-015 (30 kN) High Temp. Wedge Grip - Parts List
Item Description Part Number Quantity
1Screw M4 x 8 201S87 1
2 Bearing Pad T566-5 1
3 Body T566-54 1
4 Control Nut T566-51 1
5Spindle T566-52 1
6 Pin, 10 x 35 54-53-1056 1
7 Check Nut T2-309 1
8 Handle T566-50 4
9 Bearing Washer T566-53 1
10 Pin, 6 x 14 705J149 1
11 Pin, 1/4 x 1 in. 54-5-11 4
12 Pin, 5/32 x 1 in. 304C1 4
13 Spring Extension 66-2-1020 4
14 Side Plate T566-56 2
15 Screw M4 x 8 204F123 4
16 Specimen Centering Device
Including:
2716-011 1
Bracket T566-14 1
Thumbscrew 71-2-55 1
Stop T566-115 1
Screws 201T98 2
17 Faces Refer to
Table 3 on page 22
2 pair
