3-9
Transporting Dual Column Frames
Product Support: www.instron.com
6. Place the load frame carefully into position.
7. Remove the lifting straps from the crosshead, and any protective padding, if used.
When the frame is in its testing location, you can proceed with the installation process.
Figure 3-3. Lifting Load Frame with a Crane
Lifting sling
Crane hook
Crosshead
Load frame
