insys icom EBW-E100 - Connections; Front Panel Connections

EBW-E100
Connections
21
7 Connections
7.1 Front Panel Connections
Figure 2: Connections on the front panel of the device
Position
Description
1
Ethernet port LAN 1 (RJ45, 10/100 BT)
2
Ethernet port LAN 2 / ext. (RJ45, 10/100 BT)
Table 6: Description of the connections on the front panel of the device
