11 Operating Principle
This chapter describes how to operate and configure the EBW-E100.
Configuration and operation are performed using a web-based interface (web
interface). The web interface itself is displayed and operated using a web browser.
11.1 Operating the Web Interface
The web interface allows easy configuration using a web browser. All
functions can be configured via the web interface. The operation is mostly
self-explanatory. The web interface also provides an online help feature, which
describes the meaning of possible settings The online help is displayed by
selecting the option "Display help text" in the title bar below the language
selection.
We urgently recommend to enable online help for the first
configurations to allow a quick and flawless configuration.
Configuring with the web interface
How to configure with the web interface basically.
The device is ready for operation and you have access to it (refer to
Commissioning section).
1. Start the web browser and enter the IP address into the address bar.
The factory default IP address is 192.168.1.1.
A dialogue will prompt you to enter the user name and the password
for authentication.
2. Enter the user name and the password and click OK.
The default setting of the web interface is as follows:
the user name is "insys", the password is "icom".
The start page of the web interface is displayed.
3. Use the menu on the left side to select the menu item, in which you
want to change settings.
4. Enter the required settings.
5. Click on the button OK on the according configuration page to save
the settings.
After you completed the configuration changes, always click the
button OK . Otherwise the settings will not be taken over as soon as
you change to another page or close the browser.
