2. 2. Handling, transport and storage
The manufacturer assumes no responsibility if the following safety instructions and instructions are followed precautionary meas-
ures are not observed:
l
Any changes made to the unit without the prior written consent of the manufacturer will result in the following leads to the
immediate expiration of product liability and warranty
l
Installation, operation, maintenance and decommissioning of this device may only be carried out by trained personnel, by
qualified specialist personnel who have been instructed by the manufacturer, operator or owner to of the plant authorized.
The specialist must have read and understood all of these operating instructions and the have read and understood the
installation instructions and have understood the instructions contained therein. to the rules of the law
l
Check all connections, settings and technical data of peripheral devices
l
Open housing or parts of the housing are completely forbidden
l
The specified classifications for mechanical loads (e.g. pressure, temperature, etc.) must be observed. Protection class IP
must not be exceeded
l
Only operate the system under the specified ambient conditions and installation positions
l
Protect the system against over-voltage. In particular, electrical welding is prevented on the associated equipment
l
None of the information contained in this manual or in any other document releases the user from the responsibility for
planners assessment of the respective system configuration with regard to functionality and operational safety
l
The local labor and safety laws and regulations must be observed
2. 3. Disposal rules for RUBIN® SONIC Smart
WARNING
Warning
The device must not be opened. The battery is permanently installed and cannot be changed.
This device must not be disposed together with the domestic waste. Please return it to the manufacturer for recycling.
3. Technical characteristics
3. 1. Metrological data
Nominal diameter / thread
DN mm
50 65 80 100 125 150 200
Inches
2 2"
1/2
3 4 5 6 8
Continuous flow rate Q
3
m
3
/h
40 63 63 100 160 250 400
Overload flow rate Q
4
m
3
/h
50 78.75 78.75 125 200 313 500
Transitional flow rate Q
2
L/h
0.13 0.2 0.2 0.32 0.51 0.8 1.28
Min. flow rate Q
1
L/h
0.08 0.13 0.13 0.2 0.32 0.5 0.8
Starting flow rate Q
START
L/h
0.04 0.065 0.065 0.1 0.15 0.25 0.4
Pressure drop class @ Q
3
Δ P -
Δ P 16
Measuring range R -
R 500
Flange standard - -
ISO ANSI
BSI
ISO
ISO ANSI
BSI
ISO ANSI
BSI
ISO
ISO ANSI
BSI
ISO
PN16/10
4/13 1-320-UM-EN-03
