1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 7
SystemHouse Solutions
3 Installation Procedure
Installation procedure consist of evaluation of power requirements, mounting accessories, power
and communication lines wiring to S-Node G2, C-Node G2, Moveo, Moveo XL, mounting,
connecting cables, setting switches and verification.
Evaluate optional accessories that will be used.
If the reader shall be mounted outdoors and there is risk for that it can be exposed to rain,
proper protective housing must be used.
Evaluate power requirements as described in section 4 Power Supply
. Same time evaluate
required power cables determined by required power and length of the cables.
Select cables used for communication lines as described in section 5 Communication and
address.
Determine an appropriate mounting position for the device. The card reader is supported to be
installed on walls, mounting column, mounting brackets. The back plate of the unit contain
rubber sealing so it SHALL BE NOT used as a template for drilling. Use attached drilling
pattern instead.
Route the interface cables to S-Node G2, C-Node G2, Moveo or Moveo XL or to the other reader
if the actual reader is in the middle of the bus. Route cables to other accessories to be
connected.
Install the bottom part of BCR-SD G2 box to the wall. Feed all cables inside the box to
appropriate position and fix them to the box with cable ties.
Connect all cables to the terminals as required.
Set termination jumper SW1
to enabled (default setting) if the actual reader is placed at the end
of the bus, otherwise disable termination.
After wiring the BCR-SD G2 and accessories, device is ready to be tested. If the card reader
have been properly installed, connect terminal PL1 to the BCR-SD G2. The card reader will
beep for 1 second and starts working after short while (this is valid only in case that system was
already configured at PC level and that the parent node is up and running). This indicates that
unit is working properly.
Set the device address according requirements. Default address is “1”. For setting follow
procedure in the section Setting address
Assemble the unit by pressing the top part down on the back plate. Ensure correct positioning
in the top before it is pressed into place.
