22
En
Note
*1
Do not connect the AV controller’s USB port to a USB port on your computer. Music on your computer cannot be played through
the AV controller in this way.
*2
Connect a turntable (MM) that has a built-in phono preamp to TV/CD IN, or connect it to PHONO IN with the phono preamp turned
off. If your turntable (MM) doesn’t have a phono preamp, connect it to PHONO IN. If your turntable has a moving coil (MC) type
cartridge, you’ll need a commercially available MC head amp or MC transformer to connect to PHONO IN. See your turntable’s
manual for details.
If your turntable has a ground wire, connect it to the AV controller’s GND screw. With some turntables, connecting the ground wire
may produce an audible hum. If this happens, disconnect it.
*3
When you connect your personal computer to PC IN and select the PC input selector, the video of the personal computer is output
from the HDMI outputs. However, if you have assigned the HDMI inputs to the PC input selector, the AV controller will output
signals received from the HDMI inputs instead of signals from PC IN, based on the priority order of HDMI > component video > PC
IN (analog RGB). To have the signals output from PC IN, select “-----” for “PC” in the “HDMI Input” setting (➔ page 50).
*4
Before using the balanced input, you must assign it to an input selector. See “Balance” (➔ page 52) for
details. To select the balanced input, see “Audio Selector” (➔ page 63). The AV controller’s balanced
INPUT jacks are wired as shown.
*5
Before using the multichannel input, you must assign it to an input selector. See “Multich” (➔ page 51)
for details. To select the multichannel input, see “Audio Selector” (➔ page 63). To adjust the subwoofer sensitivity of the
multichannel input, see “Subwoofer Input Sensitivity” (➔ page 52).
• With connection E, you can enjoy Dolby Digital and DTS. (To record or listen the audio in Zone 2/3 as well, use E
and
H.)
• With connection
H, you can listen to and record audio from external components while you are in Zone 2/3.
• With connection H, if your Blu-ray Disc/DVD player has both the main stereo and multichannel outputs, be sure to
connect to the main stereo.
■ How to record a video source
With the connections described above, you cannot record the videos through the AV controller. See “Recording” about
connections for video recording (➔ page 47).
H
MONITOR OUT TV, projector, etc.
BD/DVD IN Blu-ray Disc/DVD player
VCR/DVR IN VCR or DVD recorder/digital video recorder, RI
dock
CBL/SAT IN Satellite/cable set-top box, etc.
GAME IN Game console, RI dock
PC IN
Personal computer
TV/CD IN TV, CD player, cassette tape deck, MD, CD-R,
Turntable
*2
, RI dock
PHONO IN
Turntable
*2
I
COMPONENT
VIDEO
IN 1 (BD/DVD) Blu-ray Disc/DVD player, RI dock ✔
IN 2 (CBL/SAT) Satellite/cable set-top box, RI dock, etc. ✔
IN 3 (GAME) Game console ✔
MONITOR OUT TV, projector, etc.
J
PC IN
*3
Personal computer
K
BALANCE INPUT
*4
CD player, etc. ✔
L
MULTI CH (Multichannel input)
*5
DVD player, DVD-Audio, Super Audio CD-
capable player, MPEG decorder
✔
No. Jack/Port Components Assignable
To Next Page
