Integra DRX-4.2 User Manual

129
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
 5. Analog Audio Input
Change input assignment between the input selectors and AUDIO IN jacks. If you
do not assign a jack, select "---".
Setting Item Default Value Setting Details
BD/DVD AUDIO 1 "AUDIO 1" to "AUDIO 6": Assign a desired AUDIO
IN jack to the BD/DVD button.
CBL/SAT AUDIO 2 "AUDIO 1" to "AUDIO 6": Assign a desired AUDIO
IN jack to the CBL/SAT button.
GAME AUDIO 3 "AUDIO 1" to "AUDIO 6": Assign a desired AUDIO
IN jack to the Game button.
STRM BOX AUDIO 4 "AUDIO 1" to "AUDIO 6": Assign a desired AUDIO
IN jack to the STRM Box button.
PC --- "AUDIO 1" to "AUDIO 6": Assign a desired AUDIO
IN jack to the PC button.
CD AUDIO 5 "AUDIO 1" to "AUDIO 6": Assign a desired AUDIO
IN jack to the CD button.
TV AUDIO 6 "AUDIO 1" to "AUDIO 6": Assign a desired AUDIO
IN jack to the TV button.
PHONO PHONO The setting cannot be changed.
2. Speaker
 1. Conguration
Change the settings of connection environment of the speakers.
Setting Item Default Value Setting Details
Speaker
Channels
7.1.2 ch Select "2.1 ch", "3.1 ch", "4.1 ch", "5.1 ch", "6.1
ch", "7.1 ch", "2.1.2 ch", "3.1.2 ch", "4.1.2 ch",
"5.1.2 ch", "6.1.2 ch", "7.1.2 ch", "4.1.4 ch", "5.1.4
ch", "6.1.4 ch" or "7.1.4 ch" to suit the number of
speaker channels connected.
Subwoofer Yes Set whether a subwoofer is connected or not.
"Yes": When a subwoofer is connected
"No": When a subwoofer is not connected
Height 1 Speaker Top Middle Set the speaker type if height speakers are
connected to the HEIGHT 1 terminals. Select "Front
High", "Top Front", "Top Middle", "Top Rear", "Rear
High", "Dolby Speaker (Front)", "Dolby Speaker
(Surr)", or "Dolby Speaker (Back)" according to the
type and layout of the connected speakers.
• This setting cannot be selected under any of
following conditions. Set the height speakers
type to "Height 2 Speaker".
– "Bi-Amp" is set to "Yes"
– When "Speaker Channels" is set to "2.1.2 ch",
"3.1.2 ch", "4.1.2 ch" or "5.1.2 ch", and "Zone
Speaker" is set to "Zone 2"
• When two sets of height speakers are being used,
"Top Rear", "Rear High", "Dolby Speaker (Surr)",
and "Dolby Speaker (Back)" cannot be selected.
• "Dolby Speaker (Surr)" and "Dolby Speaker (Back)"
can only be selected when surround speakers
or surround back speakers are being used,
respectively. You can check speakers that you are
using on the gure displayed in "Speaker Channels".
• If an item cannot be selected even though
connection is correct, check that the settings
in "Speaker Channels" matches the number of
connected channels.
