Integra DRX-4.2 User Manual

130
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Setting Item Default Value Setting Details
Height 2 Speaker Rear High Set the speaker type if height speakers are
connected to the HEIGHT 2 terminals. Select
"Front High", "Top Front", "Top Middle", "Top
Rear", "Rear High", "Dolby Speaker (Front)",
"Dolby Speaker (Surr)" or "Dolby Speaker (Back)"
according to the type and layout of the connected
speakers. However, the options selectable for the
"Height 1 Speaker" the are as follows.
If "Height 1 Speaker" is set to "Front High": Select
from "Top Middle", "Top Rear", "Rear High", "Dolby
Speaker (Surr)" or "Dolby Speaker (Back)".
If "Height 1 Speaker" is set to "Top Front" or "Dolby
Speaker (Front)": Select from "Top Rear", "Rear High",
"Dolby Speaker (Surr)" or "Dolby Speaker (Back)".
If "Height 1 Speaker" is set to "Top Middle": Fixed
to "Rear High".
• "Dolby Speaker (Surr)" and "Dolby Speaker
(Back)" can only be selected when surround
speakers or surround back speakers are being
used, respectively. You can check speakers that
you are using on the gure displayed in "Speaker
Channels".
• If an item cannot be selected even though
connection is correct, check that the settings
in "Speaker Channels" matches the number of
connected channels.
Zone Speaker No Set whether speakers are connected to Zone 2 or
Zone 3 speaker terminals.
"Zone 2": When speakers are connected to Zone 2
speaker terminals
"Zone 2/Zone 3": When connecting speaker to both
ZONE 2 speaker terminal and Zone 3 speaker
terminals.
• This setting cannot be selected under any of
following conditions.
– When the surround back speakers are used
– When 2 sets of height speakers are used
"No": When speakers are not connected to Zone 2
speaker terminals
Setting Item Default Value Setting Details
Bi-Amp No Set whether the front speakers are bi-amp
connected.
"No": When front speakers are not bi-amp
connected
"Yes": When front speakers are bi-amp connected
• This setting will be set to "No" in either of
following cases.
– When 2 sets of height speakers are used
– When surround back speakers and height
speakers are being used at the same time.
– When "Zone Speaker" is set to "Zone 2" or
"Zone 2/Zone 3"
Speaker
Impedance
6ohms Set the impedance (Ω) of the connected speakers.
"4ohms": When any of the connected speakers
have 4 Ω or more to less than 6 Ω impedance
"6ohms": When the connected speakers all have
6 Ω or more impedance
• For impedance, check the indications on the
back of the speakers or their instruction manual.
 2. Crossover
Change the settings of crossover frequencies.
• As for the THX-certied speakers, the following settings are recommended.
– Crossover frequency → "80Hz(THX)"
– "LPF of LFE" → "80Hz"
– "Double Bass" → "O󰀨"
Setting Item Default Value Setting Details
Front 80Hz (THX) Select the crossover frequency from "40Hz" to
"200Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
• If "Conguration" - "Subwoofer" is set to "No",
"Front" is xed to "Full Band", and the low
pitched range of the other channels is output
from the front speakers. Refer to the instruction
manual of your speakers to make the setting.
