Network Section
Ethernet LAN
10BASE-T/100BASE-TX
General
Power Supply
AC 120 V, 60 Hz (North American)
AC 220 - 240 V, 50/60 Hz (Others)
Power Consumption
750 W (North American)
760 W (Others)
0.15 W (Full Standby mode)
1.5 W (Network Standby) (North American)
1.6 W (Network Standby) (Others)
0.15 W (HDMI CEC)
1.7 W (Standby mode (ALL ON)) (North American)
1.8 W (Standby mode (ALL ON)) (Others)
70 W (No-sound)
15.4 W (HDMI Standby Through) (North American)
15 W (HDMI Standby Through) (Others)
Dimensions (W × H × D)
435 mm × 174 mm × 376.5 mm
17-1/8" × 6-7/8" × 14-13/16"
Weight
11.2 kg (24.7 lbs.)
HDMI
Input
IN1 (BD/DVD), IN2 (CBL/SAT), IN3 (GAME), IN4 (STRM BOX), IN5 (PC),
IN6, AUX INPUT HDMI (front)
Output
OUT MAIN (ARC), OUT ZONE 2/SUB
Supported
Deep Color, x.v.Color™, Lip Sync, Audio Return Channel, 3D, 4K, CEC,
Extended Colorimetry (sYCC601, Adobe RGB, Adobe YCC601), Content
Type, HDR (HDR10, BT.2020, HLG), Dolby Vision
Audio Format
Dolby Atmos, Dolby TrueHD, Dolby Digital, Dolby Digital Plus, DTS, DTS:X,
DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-
ES, DTS Express, DSD, PCM
HDCP version
2.2
Maximum Video Resolution
4k 60 Hz (YCbCr 4:4:4)
HDBaseT™
IN : 1
OUT () : 1
RS232 : 1 (Path through)
IR IN : 1 (Path through)
IR OUT : 1 (Path through)
Maximum Video Resolution : 4k 60 Hz (YCbCr 4:4:4)
Use one of the following LAN cables to connect.
Cat6 (Category 6) cable: AWG23 cable or better, 100 m or less in length
Cat5e (Category 5e) cable: AWG24 cable or better, 90 m or less in length
Video Inputs
Component
IN1 (BD/DVD), IN2 (GAME)
Composite
IN1 (CBL/SAT), IN2 (STRM BOX)
Supported input resolutions
HDMI input
4K, 1080p/24, 1080p, 1080i, 720p, 480p/576p
Component input
480i/576i
Composite input
480i/576i
• Signals are output from the HDMI OUT jack of this unit to the TV with the
same resolution as the input resolution.
