12
Front Panel
PQRSTUV
P Zone 2 button: Controls the multi-zone function.
( →p100)
Off button: Switches the multi-zone function off.
Q Zone 3 button: Controls the multi-zone function.
( →p102)
Off button: Switches the multi-zone function off.
R Whole House Mode button: Enable the
WHOLE HOUSE MODE function to play the
same source in all rooms that are multi-zone-
connected. ( →p101, p103)
Off button: Switches the WHOLE HOUSE
MODE function off.
S Phones jack: Connect headphones with a
standard plug (ø1/4″/6.3 mm).
T Setup Mic jack: Connect the supplied speaker
setup microphone. ( →p157, p159)
U Input selector buttons: Switches the input to
be played.
V AUX Input HDMI jack: Connect a video camera,
etc. using an HDMI cable. ( →p63)
