145
SetupSetup
6. Hardware
Zone 3 When controlling the power of external devices linked to the
input selection in ZONE 3
Main/Zone 3 When controlling the power of external devices linked to the
input selection in the main room or in ZONE 3
Zone 2/Zone 3 When controlling the power of external devices linked to the
input selection in ZONE 2 or in ZONE 3
Main/Zone 2/
Zone 3
When controlling the power of external devices linked to the
input selection in the main room, in ZONE 2 or in ZONE 3
• Only "Off" and "Main" are available for selection with AUX input.
6. 12V Trigger B
Set when outputting the control signal (maximum 12 V/25 mA) through the 12V
TRIGGER OUT B jack. You can enable power link operation when you connect
the unit and the external devices equipped with 12V trigger input jack.
Delay (Default Value: 1 sec)
Set after how many seconds the 12V trigger output will occur in response to
the unit's operation. As some devices cause a large current when they turn on,
delay the output if such devices are connected. Select a value between "0 sec"
to "3 sec".
BD/DVD (Default Value: Zone 2)
GAME (Default Value: Zone 2)
CBL/SAT (Default Value: Zone 2)
STRM BOX (Default Value: Zone 2)
PC (Default Value: Zone 2)
AUX (Default Value: Off)
CD (Default Value: Zone 2)
TV (Default Value: Zone 2)
PHONO (Default Value: Zone 2)
TUNER (Default Value: Zone 2)
NET (Default Value: Zone 2)
BLUETOOTH (Default Value: Zone 2)
Set the 12V trigger output setting to each input.
Off When the control signal is not output
Main When controlling the power of external devices linked to the
input selection in the main room
Zone 2 When controlling the power of external devices linked to the
input selection in ZONE 2
Main/Zone 2 When controlling the power of external devices linked to the
input selection in the main room or in ZONE 2
To Next Page
