Integra DRX-5.4 - Page 203

203
Appendix
Audio Inputs North American models Australian models
Analog 7 (Including 1×PHONO)
Digital
2 (COA XIAL×1, OPT I CAL×1)
• Supported sampling rates for PCM signals (stereo, mono) from a digital input are 32 kHz, 44.1 kHz, 48 kHz,
88.2 kHz, 96 kHz/16 bit, 20 bit, and 24 bit.
Audio Outputs North American models Australian models
Analog
FRONT L/R, CENTER, SURROUND L/R, HEIGHT 1 L/R, SURROUND BACK L/R, HEIGHT 2 L/R or
ZONE 3 L/R, 2 SUBWOOFER, ZONE B LINE OUT or ZONE 2 PRE/LINE OUT, HEIGHT 2 PREOUT or ZONE 3
PRE/LINE OUT
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R, HEIGHT 1 L/R or Bi-AMP, SURROUND BACK L/R or HEIGHT 2 L/R or
ZONE 3 L/R, ZONE 2 L/R (North American models support banana plugs)
Phones 1 (ø 6.3 mm, 1/4")
Others North American models Australian models
Setup Mic 1 (Front)
RS-232 1
12V TRIGGER OUT 3 (A:100 mA, B:25 mA, C:25 mA)
IR IN × 2(A/B), OUT × 1
Specications and features are subject to change without notice.
