Integra DRX-5.4 - Page 46

7.1. 2c h
7.1ch
5.1.2ch
5.1.4ch
7.1.4ch
5.1ch
46
Speaker Connections
 5.1.2 Channel System + ZONE SPEAKER
FL FR
SL SR
C
SW
HL HR
HR HL FR
(
Z2
) (
Z2
)
FL
C
SR SLFR FL
SW
ZONE 2
FL(Z2)FR(Z2)
MAIN ROOM
*1 Connect the Height Speakers you have actually installed (HL/HR: Height Speakers, Top Speakers, Dolby Enabled Speakers).
*1
