Integra DRX-5 Basic Manual

29
|
> Specifications > Settings > Listening Modes > Playback Function > Basic Manual
Troubleshooting Appendix
Setting Item Default Value Setting Details
CD Main/Zone 2/
Zone 3
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
CD
" is selected as input for
main room.
"Zone 2": Output when "
CD
" is selected as input for
ZONE2.
"Main/Zone 2": Output when "
CD
" is selected as
input for main room or ZONE2
.
"
Zone 3
"
: Output when
"CD"
is selected as
input
for
ZONE3.
"
Main/Zone 3
"
: Output when
"CD"
is selected as
input for main room or ZONE3.
"
Zone 2/Zone 3
"
: Output when
"CD"
is selected as
input for ZONE2 or ZONE3.
"
Main/Zone 2/Zone 3
"
: Output when
"CD"
is
selected as input for main room, ZONE2 or
ZONE3.
TV Main/Zone 2/
Zone 3
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
TV
" is selected as input for
main room.
"Zone 2": Output when "
TV
" is selected as input for
ZONE2.
"Main/Zone 2": Output when "
TV
" is selected as
input for main room or ZONE2
.
"
Zone 3
"
: Output when
"TV"
is selected as
input
for
ZONE3.
"
Main/Zone 3
"
: Output when
"TV"
is selected as
input for main room or ZONE3.
"
Zone 2/Zone 3
"
: Output when
"TV"
is selected as
input for ZONE2 or ZONE3.
"
Main/Zone 2/Zone 3
"
: Output when
"TV"
is
selected as input for main room, ZONE2 or
ZONE3.
Setting Item Default Value Setting Details
PHONO Main/Zone 2/
Zone 3
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
PHONO
" is selected as input
for main room.
"Zone 2": Output when "
PHONO
" is selected as
input for ZONE2.
"Main/Zone 2": Output when "
PHONO
" is selected
as input for main room or ZONE2
.
"
Zone 3
"
: Output when
"PHONO"
is selected as
input
for ZONE3.
"
Main/Zone 3
"
: Output when
"PHONO"
is selected
as input for main room or ZONE3.
"
Zone 2/Zone 3
"
: Output when
"PHONO"
is
selected as input for ZONE2 or ZONE3.
"
Main/Zone 2/Zone 3
"
: Output when
"PHONO"
is selected as input for main room, ZONE2 or
ZONE3.
TUNER Main/Zone 2/
Zone 3
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
TUNER
" is selected as input
for main room.
"Zone 2": Output when "
TUNER
" is selected as
input for ZONE2.
"Main/Zone 2": Output when "
TUNER
" is selected
as input for main room or ZONE2
.
"
Zone 3
"
: Output when
"TUNER"
is selected as
input
for ZONE3.
"
Main/Zone 3
"
: Output when
"TUNER"
is selected
as input for main room or ZONE3.
"
Zone 2/Zone 3
"
: Output when
"TUNER"
is
selected as input for ZONE2 or ZONE3.
"
Main/Zone 2/Zone 3
"
: Output when
"TUNER"
is selected as input for main room, ZONE2 or
ZONE3.
