Integra DTR-4.9 - Trans. Sec. Terminal Pc Board (Naps

21/76 PAGE
PCB2
U22
TRANS. SEC. TERMINAL PC BOARD (NAPS-9447-1D)
PCB2
U23
SETUP MIC JACK PC BOARD (NAETC-9448-1D)
PCB2
U24
HEADPHONE JACK PC BOARD (NAETC-9449-1D)
PCB2
U25
INLET PC BOARD (NAETC-9451-1D)
PCB2
U26
ZONE 2 / IR PC BOARD (NAETC-9452-1D)
PCB2
PCB2
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PCB2
U7041 REMO SENS NJL34H380A 1 241365
PCB2
Q6310 IC M61540FP 1 22242497R2
PCB2
Q6311 IC ICL3221ECVZ 1 22242268R2
PCB2
Q6312 TR KTA1266-GR 1 2215975T
PCB2
Q6312 or TR 2SA1015-GR (1) 2211455T
PCB2
Q6313 TR 2SB1240-R 1 2213794T
PCB2
Q6314 TR KRC102M 1 2215960T
PCB2
Q6314 or TR DTC114ES (1) 2213290T
PCB2
Q6315 TR KRC102M 1 2215960T
PCB2
Q6315 or TR DTC114ES (1) 2213290T
PCB2
Q6316 TR KTA1266-GR 1 2215975T
PCB2
Q6316 or TR 2SA1015-GR (1) 2211455T
PCB2
Q6317 TR KRC102M 1 2215960T
PCB2
Q6317 or TR DTC114ES (1) 2213290T
PCB2
Q6318 TR KRA102M 1 2215770T
PCB2
Q6318 or TR DTA114ES (1) 2213510T
PCB2
Q6319 PHT CP TLP421(BL_J) 1 24120103
PCB2
Q6319 or PHT CP PC817X (1) 24120080
PCB2
Q6320 PHT CP TLP421(BL_J) 1 24120103
PCB2
Q6320 or PHT CP PC817X (1) 24120080
PCB2
Q6321 TR RN1241-A(TPE4_F) 1 2213631T
PCB2
Q6322 TR RN1241-A(TPE4_F) 1 2213631T
PCB2
Q7002 FL TUBE 16-BT-138GNK 1 212268
PCB2
Q7002A HOLDER (FL) 1 27191222C
PCB2
Q7003 IC M66005-0001AHP 1 22242208R3
PCB2
Q7004 TR 2SC2458-GR 1 2212115T
