Integra DTR-4.9 - Pc Board Parts List

5/76 PAGE
EXPLODED
U32 MICROPROCESSOR PC board ass'y NADG-9462-1R* 1 1B211562-1R
EXPLODED
U35 E-CONTROL PC board ass'y NALAN-9465-1R 1 1B211565-1R
EXPLODED
U36 VIDEO PC board ass'y NAVD-9467-1V* 1 1B211567-1V
EXPLODED
U37 SPEAKER TERMINAL PC board ass'y NATRM-9468-1V 1 1B211568-1V
EXPLODED
U38
DRIVER AMPLIFIER PC board ass'y
NACLA-9470-1B* 1 1B211570-1B
EXPLODED
U44 HDMI PC board ass'y NAHDM-9565-1B* 1 1B211565-1B
EXPLODED
U45 TUNER UNIT ENG06507QFUS 1 240156
EXPLODED
U45 or TUNER UNIT FAE385-A11US (1) 240152
DTR-4.9
PC BOARD PARTS LIS
T
PCB1
U05
AMPLIFIER PC BOARD (NAAF-9424-1E)
PCB1
U06
TRANS. SEC. TERMINAL PC BOARD (NAPS-9425-1E)
PCB1
U07
THERMAL SENSOR PC BOARD (NAETC-9426-1E)
PCB1
PCB1
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PCB1
Q5501 IC R2S15211FP 1 22242297R3
PCB1
Q5503 IC NE5532APSR 1 22242283R2
PCB1
Q5600 TR RN1441 1 2215410R2
PCB1
Q5603 TR RN1441 1 2215410R2
PCB1
Q5604 TR RN1441 1 2215410R2
PCB1
Q5605 TR RN1441 1 2215410R2
PCB1
Q5606 TR RN1441 1 2215410R2
PCB1
Q5607 TR RN1441 1 2215410R2
PCB1
Q5610 TR RN1441 1 2215410R2
PCB1
Q5630 IC NE5532APSR 1 22242283R2
PCB1
Q5670 IC 78M15HF(NJM78M15FA) 1 222780155JRC
PCB1
Q5670 or IC UPC78M15AHF-AZ (1) 222780155NEC
PCB1
Q5670A HEAT SINK RAD-196 1 27160545
PCB1
Q5670B SCREW 3P+10FN(3BC) 1 82143010GR
PCB1
Q5671 IC 79M15HF(NJM79M15FA) 1 222790155JRC
PCB1
Q5671 or IC UPC79M15HF-AZ (1) 222790155NEC
