Integra DTR-4.9 - Page 94

4/76 PAGE
EXPLODED
Q6062 or TR MP130S-P (1) 2203676
!
EXPLODED
Q6063 TR MP130S-O 1 2203673
!
EXPLODED
Q6063 or TR MP130S-Y (1) 2203674
!
EXPLODED
Q6063 or TR MP130S-P (1) 2203676
!
EXPLODED
Q6064 TR MP130S-O 1 2203673
!
EXPLODED
Q6064 or TR MP130S-Y (1) 2203674
!
EXPLODED
Q6064 or TR MP130S-P (1) 2203676
!
EXPLODED
<Note>
EXPLODED
Must use the same HFE rank mutually about the following parts.
EXPLODED
Ref. No. : Q6050 - 6054, Q6060 - Q6064
EXPLODED
T901 P TRANS NPT-1552D 1 2301888
!
EXPLODED
F901 FUSE 10A-UL/T-233 1 252330GR
!
EXPLODED
F901 or FUSE 10A-T/UL-ST2 (1) 252333GR
!
EXPLODED
F910 FUSE 5A-UL/T-233 1 252326GR
!
EXPLODED
F910 or FUSE 5A-T/UL-ST2 (1) 252258GR
!
EXPLODED
F6901 FUSE 12A-TUL-250V 1 252301GR
!
EXPLODED
F6902 FUSE 12A-TUL-250V 1 252301GR
!
EXPLODED
P101 FFC NCFC7-132512 1 2047132512
EXPLODED
P701 FFC NCFC7-334012 1 2047334012
EXPLODED
U05 AMPLIFIER PC board ass'y NAAF-9424-1E* 1 1B211524-1E
EXPLODED
U06
TRANS. SEC. TERMINAL PC board ass'y
NAPS-9425-1E 1 1B211525-1E
EXPLODED
U07 THERMAL SENSOR PC board ass'y NAETC-9426-1E 1 ---
NSP
EXPLODED
U08 HOLDER PC board NAETC-9427-1 1 ---
NSP
EXPLODED
U19 DISPLAY PC board ass'y NADIS-9444-1D* 1 1B211544-1D
EXPLODED
U20 VOLUME PC board ass'y NADIS-9445-1D 1 1B211545-1D
EXPLODED
U21 POWER SUPPLY PC board ass'y NAPS-9446-1D 1 1B211546-1D
EXPLODED
U22
TRANS. SEC. TERMINAL PC board ass'y
NAPS-9447-1D 1 1B211547-1D
EXPLODED
U24 HEADPHONE JACK PC board ass'y NAETC-9449-1D 1 --- NSP
EXPLODED
U25 INLET PC board ass'y NAETC-9451-1D 1 --- NSP
EXPLODED
U26 ZONE 2 / IR PC board ass'y NAETC-9452-1D 1 --- NSP
EXPLODED
U27 HOLDER PC board NAETC-9454-1 1 --- NSP
EXPLODED
U28 HOLDER PC board NAETC-9455-1 1 --- NSP
EXPLODED
U29 HOLDER PC board ass'y NAETC-9456-1D 1 --- NSP
