Integra DTR-4.9 - Exploded View Parts List

1/76 PAGE
DTR-4.9
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED
A001 F BRACKET DTR-5.9(B) 1 27111502
EXPLODED
A002 F PANEL (B)MDD/DTR49 1 27213104A
EXPLODED
A003 KNOB (STANDBY) 1 28325756
EXPLODED
A004 CLEAR PLT --- 1 28192078
EXPLODED
A005 BADGE --- 1 28135278
EXPLODED
A006 CUSHION --- 3 28141650
EXPLODED
A007 DECO FRM --- 1 27215377
EXPLODED
A008 FACET --- 2 28198905
EXPLODED
A009 B PLATE --- 1 28133418
EXPLODED
A010 RETAINER (HP) 1 27141787
EXPLODED
A011 SCREW 3TTB+8B(3BC) 3 838430088GR
EXPLODED
A012 REAR PANEL DTR-4.9MDD 1 27123808
EXPLODED
A013 SCREW 3TTB+8B(3CM)SR 5 801637
EXPLODED
A014 SCREW 3P+6FN(3BC) 4 82143006GR
EXPLODED
A015 SCREW 3TTB+8B(3CM)SR 13 801637
EXPLODED
A016 SCREW 3TTB+8B(3BC) 38 838430088GR
EXPLODED
A017 LABEL (COVER) 1 29364123
EXPLODED
A018 SCREW 3TTB+8B(3CM)SR 2 801637
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
