Integra DTR-40.7 - Page 83

Advanced Settings (Setup Menu)
En-51
Setting Item Default Value Setting Details
PC Main Set the 12V trigger output setting to each
input�
"Off": No output
"Main": Output when "PC" is selected as input
for main room�
"Zone2": Output when "PC" is selected as
input for ZONE2�
"Main/Zone2": Output when "PC" is selected
as input for main room or ZONE2�
GAME Main Set the 12V trigger output setting to each
input�
"Off": No output
"Main": Output when "GAME" is selected as
input for main room�
"Zone2": Output when "GAME" is selected as
input for ZONE2�
"Main/Zone2": Output when "GAME" is
selected as input for main room or ZONE2�
AUX Main Set the 12V trigger output setting to each
input�
"Off": No output
"Main": Output when "AUX" is selected as
input for main room�
CD Main Set the 12V trigger output setting to each
input�
"Off": No output
"Main": Output when "CD" is selected as input
for main room�
"Zone2": Output when "CD" is selected as
input for ZONE2�
"Main/Zone2": Output when "CD" is selected
as input for main room or ZONE2�
Setting Item Default Value Setting Details
PHONO Main Set the 12V trigger output setting to each
input�
"Off": No output
"Main": Output when "PHONO" is selected as
input for main room�
"Zone2": Output when "PHONO" is selected
as input for ZONE2�
"Main/Zone2": Output when "PHONO" is
selected as input for main room or ZONE2�
TV Main Set the 12V trigger output setting to each
input�
"Off": No output
"Main": Output when "TV" is selected as input
for main room�
"Zone2": Output when "TV" is selected as
input for ZONE2�
"Main/Zone2": Output when "TV" is selected
as input for main room or ZONE2�
TUNER Main Set the 12V trigger output setting to each
input�
"Off": No output
"Main": Output when "TUNER" is selected as
input for main room�
"Zone2": Output when "TUNER" is selected
as input for ZONE2�
"Main/Zone2": Output when "TUNER" is
selected as input for main room or ZONE2�
NET Main Set the 12V trigger output setting to each
input�
"Off": No output
"Main": Output when "NET" is selected as
input for main room�
"Zone2": Output when "NET" is selected as
input for ZONE2�
"Main/Zone2": Output when "NET" is selected
as input for main room or ZONE2�
