DTR-5.9
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
<MDD> : USA model
<MPA> : Australian model
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED
A001 F BRACKET DTR-5.9(B) 1 27111502
EXPLODED
A002 F PANEL (B)MDD/DTR59 1 27213101A
<MDD>
EXPLODED
A002 F PANEL (B)MPP/DTR59 1 27213102A
<MPA>
EXPLODED
A003 KNOB (STANDBY) 1 28325756
EXPLODED
A004 CLEAR PLT --- 1 28192078
EXPLODED
A005 BADGE --- 1 28135278
EXPLODED
A006 CUSHION --- 3 28141650
EXPLODED
A007 DECO FRM --- 1 27215377
EXPLODED
A008 FACET --- 2 28198905
EXPLODED
A009 B PLATE --- 1 28133418
EXPLODED
A010 RETAINER (HP) 1 27141787
EXPLODED
A011 SCREW 3TTB+8B(3BC) 3 838430088GR
EXPLODED
A012 REAR PANEL DTR-5.9MDD 1 27123810A
<MDD>
EXPLODED
A012 REAR PANEL DTR-5.9MPP/MPA 1 27123811A
<MPA>
EXPLODED
A013 SCREW 3TTB+8B(3CM)SR 5 801637
EXPLODED
A014 SCREW 3P+6FN(3BC) 5 82143006GR
EXPLODED
A015 SCREW 3TTB+8B(3CM)SR 13 801637
EXPLODED
A016 SCREW 3TTB+8B(3BC) 42 838430088GR
<MDD>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
