6/98 PAGE
EXPLODED
F6902 FUSE 12A-TUL-250V 1 252301GR
!
EXPLODED
P101 FFC NCFC7-132512 1 2047132512
EXPLODED
P701 FFC NCFC7-334012 1 2047334012
EXPLODED
P2801 FFC NCFC7-131012 1 2047131012
EXPLODED
U05 AMPLIFIER PC board ass'y NAAF-9424-1G* 1 1B211524-1G
<MDD>
EXPLODED
U05 AMPLIFIER PC board ass'y NAAF-9424-1H* 1 1B211524-1H
<MPA>
EXPLODED
U06
TRANS. SEC. TERMINAL PC board ass'y
NAPS-9425-1G 1 1B211525-1G
<MDD>
EXPLODED
U06
TRANS. SEC. TERMINAL PC board ass'y
NAPS-9425-1H 1 1B211525-1H
<MPA>
EXPLODED
U07 THERMAL SENSOR PC board ass'y NAETC-9426-1G 1 ---
<MDD> NSP
EXPLODED
U07 THERMAL SENSOR PC board ass'y NAETC-9426-1H 1 ---
<MPA> NSP
EXPLODED
U08 HOLDER PC board NAETC-9427-1 1 ---
NSP
EXPLODED
U09
ZONE 2 SPEAKER TERMINAL PC board ass'y
NATRM-9428-1G 1 1B211528-1G
<MDD>
EXPLODED
U09
ZONE 2 SPEAKER TERMINAL PC board ass'y
NATRM-9428-1H 1 1B211528-1H
<MPA>
EXPLODED
U19 DISPLAY PC board ass'y NADIS-9444-1A* 1 1B211544-1A
<MDD>
EXPLODED
U19 DISPLAY PC board ass'y NADIS-9444-1B* 1 1B211544-1B
<MPA>
EXPLODED
U20 VOLUME PC board ass'y NADIS-9445-1A 1 1B211545-1A
<MDD>
EXPLODED
U20 VOLUME PC board ass'y NADIS-9445-1B 1 1B211545-1B
<MPA>
EXPLODED
U21 POWER SUPPLY PC board ass'y NAPS-9446-1A 1 1B211546-1A
<MDD>
EXPLODED
U21 POWER SUPPLY PC board ass'y NAPS-9446-1B 1 1B211546-1B
<MPA>
EXPLODED
U22
TRANS. SEC. TERMINAL PC board ass'y
NAPS-9447-1A 1 1B211547-1A
<MDD>
EXPLODED
U22
TRANS. SEC. TERMINAL PC board ass'y
NAPS-9447-1B 1 1B211547-1B
<MPA>
EXPLODED
U23 SETUP MIC JACK PC board ass'y NAETC-9448-1A 1 ---
<MDD> NSP
EXPLODED
U23 SETUP MIC JACK PC board ass'y NAETC-9448-1B 1 ---
<MPA> NSP
EXPLODED
U24 HEADPHONE JACK PC board ass'y NAETC-9449-1A 1 ---
<MDD> NSP
EXPLODED
U24 HEADPHONE JACK PC board ass'y NAETC-9449-1B 1 ---
<MPA> NSP
EXPLODED
U25 INLET PC board ass'y NAETC-9451-1A 1 ---
<MDD> NSP
EXPLODED
U25 INLET PC board ass'y NAETC-9451-1B 1 ---
<MPA> NSP
EXPLODED
U26 ZONE 2 / IR PC board ass'y NAETC-9452-1A 1 ---
<MDD> NSP
EXPLODED
U26 ZONE 2 / IR PC board ass'y NAETC-9452-1B 1 ---
<MPA> NSP
EXPLODED
U27 HOLDER PC board NAETC-9454-1 1 ---
NSP
EXPLODED
U29 HOLDER PC board NAETC-9456-1 1 ---
NSP
EXPLODED
U32 MICROPROCESSOR PC board ass'y NADG-9462-1U* 1 1B211562-1U
<MDD>
EXPLODED
U32 MICROPROCESSOR PC board ass'y NADG-9462-1V* 1 1B211562-1V
<MPA>
