57/98 PAGE
PCB3
JL6016 JMP LEAD JL11 350 B 1 ---
NSP
PCB3
JL6016A WIRE HOL NSCT-11P882 1 25051095
PCB3
JL6402B WIRE TRAP NPLG-3P586 1 25055624
PCB4
U36
VIDEO PC BOARD (NAVD-9467-1X / 1Z)
PCB4
U37
SPEAKER TERMINAL PC BOARD (NATRM-9468-1X / 1Z)
PCB4
PCB4
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN)
REMARKS
PCB4
Q3001 IC AN15880A-VT 1 22242319R3
PCB4
Q6601 TR KRC105S 1 2217290R2
PCB4
Q6601 or TR RN1405 (1) 2214500R2
PCB4
Q6602 TR KRC105S 1 2217290R2
PCB4
Q6602 or TR RN1405 (1) 2214500R2
PCB4
Q6603 TR KRC105S 1 2217290R2
PCB4
Q6603 or TR RN1405 (1) 2214500R2
PCB4
Q6604 TR KRC105S 1 2217290R2
PCB4
Q6604 or TR RN1405 (1) 2214500R2
PCB4
Q9001 TR 2SC2235-Y(TPE6_F) 1 2211654T
PCB4
Q9001 or TR 2SC2235-O(TPE6_F) (1) 2211653T
PCB4
Q9002 TR KRC105S 1 2217290R2
PCB4
Q9002 or TR RN1405 (1) 2214500R2
PCB4
Q9022 IC MPC2905BHF 1 22278005DBNE
PCB4
Q9022 or IC 78M05AHF(MPC78M05AHF) (1) 222780055NEC
PCB4
Q9031 IC MPC2905BHF 1 22278005DBNE
PCB4
Q9031A SCREW 3P+10FN(3BC) 1 82143010GR
PCB4
Q9031B HEAT SINK RAD-140 1 27160471
PCB4
D3028 C-DIODE KDS4148U 1 223283R2
PCB4
D3028 or C-DIODE 1SS352 (1) 223234R2
PCB4
D3028 or C-DIODE MA2J111 (1) 223279R2
PCB4
D3029 C-DIODE KDS4148U 1 223283R2
PCB4
D3029 or C-DIODE 1SS352 (1) 223234R2
PCB4
D3029 or C-DIODE MA2J111 (1) 223279R2
PCB4
D6600 C-DIODE KDS4148U 1 223283R2
