DSP CIRCUIT PC BOARD (NADG-7952-2B/2C)
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Q110,Q111 22241383R2 or NJM4565M-D or
Q300 22240581R2 NJM4565M
Q113,Q114 22241943R2 CS5333-KZ
Q301 22241787R3 TC9274F-020
Q302 22241761R3 BD3811K1
Q303~Q306 22241383R2 or NJM4565M-D or
22240581R2 NJM4565M
Q307,Q308 22241383R2 or NJM4565M-D or
22240581R2 NJM4565M
Q309,Q310 22241785R2 BD3812F
Q311 222780073R2 78L07(SMT)
Q312 222790073R2 79L07(SMT)
Q700 22241947R3 MB86D42PFV
Q7001 22241982R3 MPD703030BYGC-J03-8EU
Q7005 22274000GR2TO TC74VHCT00AFT
Q7006 22274004HR2TO TC74VHCU04FT
Q701 22274074ER2TO or TC74VHC74FT or
22274074IR2TI SN74AHC74PWR
Q703 22241847R3 MB86344BPFV
Q704 22240935R2 TC7WU04FU
Q705,Q706 22241887R2 or CY7C1019CV33-15VCT or
22241612R2 CY7C1019BV33-15VCT
Q707 22240935R2 TC7WU04FU
Q751 22274074ER2TO or TC74VHC74FT or
22274074IR2TI SN74AHC74PWR
Q800 22241945R3 CS42528-CQ
Q801~Q804 22241383R2 or NJM4565M-D or
22240581R2 NJM4565M
Q9501 222780125 78M12HF
Q9502 222790125 79M12HF
Q9506 222780054NEC MPC7805HF
Q9508 22278028DR2JR NJM2391DL1-285
Q9509 22278033BR2JR NJU7200U33
Q9510 22278033DR2NE or MPC2933T or
22278033DR2JR NJM2391DL1-33
Q9512 222790055 79M05FA
Q9513 222780053R2JR NJM78L05UA
Transistors
Q400,Q401 2214530R2 or RN2402 or
2216220R2 KRA102S
Q402 2214530R2 or RN2402 or
2216220R2 KRA102S
Q403,Q404 2214490R2 or RN1404 or
2216210R2 KRC104S
Q405 2214490R2 or RN1404 or
2216210R2 KRC104S
Q7002 2214490R2 or RN1404 or
2216210R2 KRC104S
Q9503 2215024 2SD1468S-R
Q9504 2212853 or 2SB1068-K or
