R9505 441623304 RS1WBJ-33,Metal oxide
R9507 441720394 RS2WBJ-3.9,Metal oxide
R9510 441720154 RS2WBJ-1.5,Metal oxide
Terminals
P300 25045565 or NPJ-6PDBL380 or
25045583 NPJ-6PDRW394
P301,P302 25045565 or NPJ-6PDBL380 or
25045583 NPJ-6PDRW394
P303 25045734 NPJ-6PDWRLEGP522
Sockets
JL9501B 25050269 NSCT-5P97
P101A 25052211 or NSCT-15P2108 or
25051822 NSCT-15P1609
P101A 25051814 NSCT-7P1601
P308 2009990788UL NSAS-26P1149
P309 2009990789UL NSAS-6P1150
P6931B 25052579R2 NSCT-13P2476
P7501B 25052574R2 NSCT-8P2471
Plugs
P105B,P107B 25055712 NPLG-20P668
P2808A 25055149 NPLG-5P133
P304 25055133 NPLG-3P117
P7503B 25055624 NPLG-3P586
P7701 25055704 NPLG-8P660
Heat sink
Q9501B 27160500 RAD-165
Isolated sheet
Q9507B 223026 ISO SHEET
Isolated washer
Q9507C 223032 TO-66(1)
Pan head screws
D9005B,Q9501A 82143010 3P+10FN(BC)
Q9506A,Q9507A 82143010 3P+10FN(BC)
VIDEO CIRCUIT PC BOARD (NADG-7953-2C)
Australian model only
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Q201~Q203 22241946R2 NJM2595M
Q204 22241779 LC74763-9836
Q205 22241221R2 TC9164AF
Q206 22241849R2 MM1512
Q211 222740046R2 74HCU04F
Photo couplers
Q207 24120080 PC817X
U201,U202 24120101 TORX179L
U203 24120102 TOTX179L
Transistors
Q208~Q210 2215510R2 RN1443
Q212~Q217 2215510R2 RN1443
Q218~Q220 2214375R2 2SA1162-GR
