Integra DTR-6.4 - Page 87

P202 25045728 NPJ-15PDBY516
P205 25045730 NPJ-10PDBY518
P206 25045647 HSJ1002-01-1020
Sockets
P207B 25051235 NSCT-10P1025
P208B 25051527 NSCT-16P1314
COMPONENT VIDEO PC BOARD (NADG-7954-2B/2C)
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Q2202 22241465R2 LA7106MFP
Q2203 22241851R3 TA1270BF
Q2217 222780053 78L05
Q2255,Q2256 22241383R2 NJM4565M-D
Transistors
Q2201 2214460R2 or RN1401 or
2216330R2 KRC101S
Q2204 2216330R2 or KRC101S or
2214460R2 RN1401
Q2211,Q2213 2212855 or 2SB1068-U or
2212853 2SB1068-K
Q2212,Q2214 2216190R2 or KRC102S or
2214470R2 RN1402
Q2215 2216185R2 or KTA1504-GR or
2214375R2 2SA1162-GR
Q2216,Q2218 2216175R2 or KTC3875-GR or
Q2219,Q2222 2213145R2 2SC2712-GR
Q2220,Q2221 2216190R2 or KRC102S or
Q2223 2214470R2 RN1402
Q2251,Q2252 2215410R2 RN1441
Q2253,Q2254 2215410R2 RN1441
Q2257 2216220R2 or KRA102S or
Q2257 or 2214530R2 RN2402
Q2271,Q2272 2215410R2 RN1441
Diodes
D2201,D2202 223234R2 or 1SS352 or
D2212 223269R2 1SS355
D2211,D2213 22380260 or RL1N4003 or
22380035 GP104003E
Oscillators
X2201 3010370 CSBLA503KECZF30,Ceramic
X2202 3010369 HC-49/U033.579545M,Crystal
Capacitors
C2203~C2205 394641007 or CE04W16V-10M(VR) or
394741007 CE04W16V10M(SC),Elect.
C2206,C2208 394621017 or CE04W6.3V-100M(VR) or
C2229 394721017 CE04W6.3V100M(SC),Elect.
C2210 394644707 or CE04W16V-47M(VR) or
394744707 CE04W16V47M(SC),Elect.
C2212 375522234 MMT50V-223J,Plastic
C2215,C2216 394641007 or CE04W16V-10M(VR) or
394741007 CE04W16V10M(SC),Elect.
C2217,C2218 374721024 ECQ-B50V-102J,Plastic
