Integra DTR-6.4 - Page 91

P2553 25045678 NPJ-3PDB475
Sockets
P209C 2009990792UL NSAS-10P1159
P2501C 2009990513UL NSAS-6P0675
P2554 25051569 NSCT-4P1356
FRONT OPTICAL INPUT PC BOARD (NADG-7964-1C)
CIRCUIT NO. PART NO. DESCRIPTION
Photo coupler
U2601 24120108 GP1FA513RZ
Coil
L2601 231237M022R2 NCH-1471
Capacitor
C2601 394621017 or CE04W6.3V-100M(VR) or
394721017 CE04W6.3V100M(SC),Elect.
Resistor
R2601 435032214R1 RN72K1J-221JE
Socket
JL7503A 25051087 NSCT-3P874
POWER AMPLIFIER PC BOARD (NAAF-7966-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q6010~Q6015 2213284 or 2SC1740S-R or
Q6020~Q6025 2213285 2SC1740S-S
Q6030~Q6032 2203010 2SC5171
Q6033~Q6035 2203434 or KTD2061-Y or
2203010 2SC5171
Q6040~Q6042 2203000 2SA1930
Q6043~Q6045 2203424 or KTB1369-Y or
2203000 2SA1930
Q6070~Q6075 2214984 or 2SC2631-R or
2214985 2SC2631-S
Q6070~Q6075 2215896, KTC3200-BL,
2215895, KTC3200-GR,
2210755, 2SC1775A-E,
2210756, 2SC1775A-F,
2211733 or 2SC1845-E or
2211732 2SC1845-F
Q6303,Q6304 2215995, KTA1267-GR,
2213354 or 2SA933S-R or
2213355 2SA933S-S
Q6601~Q6603 2215864, KTC3199-GR,
Q6901 2213284, 2SC1740S-R,
2213285 or 2SC1740S-S or
2212115 2SC2458-GR
Q6701,Q6702 2215896, KTC3200-BL,
2215895, KTC3200-GR,
2210755, 2SC1775A-E,
2210756, 2SC1775A-F,
2211733 or 2SC1845-E or
2211732 2SC1845-F
Q6703 2215885, KTA1268-GR,
