Integra DTR-6.4 - Page 93

Plugs
P6000A~P6004A 25056010 NPLG-5P0960
P6005A 25056017 NPLG-12P0967
P6080~P6085 25055038 NPLG-2P29
P6301,P6302 25055038 NPLG-2P29
P931A 25055701 NPLG-5P657
Label
F6901C 29362801 T10AL250V <A>
Heat sink
D6904A 27160499 RAD-164
Bar
P6011A 27141860 (BUS-D)
Pan head screws
Q9512A 82143010 3P+10FN(BC)
D6904B 82143010 3P+10FN(BC)
THERMAL DETECTOR PC BOARD (NAETC-7967/73-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
Thermistors
R6380 4000153 PTH9M04BF222TS2F333
R6381 4000150 PTH9M04BC222TS2F333 <A>
4000218
PTFL04BE471Q2N34B0
(
90) <D>N
Socket
JL6402B 25051088 NSCT-4P875
SPEAKER TERMINAL PC BOARD (NAETC-7968-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
Diodes
D6600,D6604 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
D6601 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
Coils and Filters
L6800~L6805 231176S S-1.3C
Capacitors
C6840~C6847 374721034 ECQ-B50V-103J,Plastic
C6850~C6857 374721024 ECQ-B50V-102J,Plastic
Resistors
RL6600,RL6601 25065563, NRL-2P5A-DC24-129,
RL6603,RL6604 25065586, NRL-2P5A-DC24-142,
25065517 or NRL-2P5A-DC24-098 or
25065636 NRL-2P5A-DC24-164
Terminals
P6802 25060334 NTM-8PDMN265 <D>
P6802 25060327 NTM-8PDMN258 <A>
P6803 25060333 NTM-8PDMN264 <D>
P6803 25060329 NTM-8PDMN260 <A>
Sockets
JL6803B,JL6804B 25050283 NSCT-6P111
JL6805B 25050281 NSCT-4P109
